6 / 6The remote control system lets the operator guide travel and mowing from a distance. The product sheet lists a 500 m control distance; actual range depends on the worksite.
The frame supports the Loncin 196 four-stroke engine, cutting system and crawler drive. The listed machine size is 940 × 940 × 550 mm.
Set the cutting height within the listed 10–200 mm range to suit tall grass, brush and the finish required. Follow the operating guide when raising or lowering the deck.
The Loncin 196 four-stroke engine and built-in 2200 W generator form the gas-electric hybrid power system. Manual start is standard, with electric start available as an option.
The paired rubber tracks and integrated gearbox support controlled travel at 0–4 km/h. The listed climbing capacity is 50°; assess traction and ground conditions before operating on slopes.
The rotating manganese-steel blade cuts tall grass, brush and dense vegetation into smaller pieces. Listed working efficiency is up to 2200 m²/h; actual coverage depends on vegetation and terrain.
Swipe to explore features
Technical specifications for YTW-550T.
| Specification | YTW-550T |
|---|---|
| Product Specifications — Simple Version | |
| Model | YTW-550T (Simple Version) |
| Product type | Tracked remote-control lawn mower |
| Cutting width | 550 mm |
| Cutting height | 10–200 mm (electric adjustment) |
| Power source | Gas-electric hybrid (manual throttle) |
| Fuel / engine output | Gasoline-powered, 9.5 hp |
| Engine | Loncin 196 four-stroke |
| Built-in generator | 2200 W |
| Drive power | 800 W × 2, integrated gearbox |
| Tracks | 32# engineering rubber tracks |
| Built-in battery | 2 × Chaowei 12.5A batteries, 24 V system |
| Starting method | Manual start; electric start optional |
| Climbing capacity | 50° |
| Remote control | Up to 500 m; high and low speed modes |
| Travel speed | 0–4 km/h |
| Working efficiency | Up to 2200 m²/h |
| Fuel tank capacity | 1.4 L |
| Engine oil capacity | 0.6 L |
| Maximum fuel consumption | 2 L/h |
| Overall dimensions | 940 × 940 × 550 mm |
| Net weight | 153 kg |
| Package size | 1030 × 1030 × 820 mm |
| Shipping weight (with package) | 188 kg |
Explore typical working environments. Share your terrain, vegetation and access conditions to confirm model suitability.
Explore equipment options for this mower. Our team will confirm compatibility for your selected model and order.
Discuss your configuration
Remote-controlled spraying attachment for applying liquids across suitable ground.
Grass collection attachment for gathering cut material during mowing.
Electrically operated plow blade for moving light snow when fitted to a compatible mower.
Rack for carrying tools and supplies on a compatible mower.
Images show accessory examples. Availability, compatibility and final appearance require confirmation for your selected model.
Contact our team and mention YTW-550T. We can confirm the current specification sheet.
Yes. Share your terrain, vegetation and working area so we can compare suitable models.
Use the Request a quote button above and include your required configuration.
Tell us your required configuration and our team will follow up with you.
